High-End Line
Inomotive® Workstation-II
Robust, compact and powerful for automotive test and validation applications
- 10th Generation Intel® Core™ i CPUs
- NVIDIA® GPU can be used for AI applications
- Data write rates of 14 GB/s
- QuickTray® Data Logging ready with 120 TB storage unit
- NVMe & SATA technology
- Individual configuration with measuring cards
- In-vehicle power supply of your choice (12 V, 24 V, 48 V)
System Description
The robust Inomotive® Workstation-II convinces with high data write rate, powerful GPU as well as individual configurability and is therefore prepared for all application areas of automotive development. 10th Generation Intel® Core™ i CPUs ensure high performance in a small space. At the same time, storage capacity of up to 120 TB enables use in high-speed data logging, and NVIDIA® GPUs deliver up to 2304 CUDA cores for computing intensive AI applications. Both NVMe and SATA technology ensure fast and constant data transfer. Even at environmental temperatures of 0° up to 55° C, the Inomotive® Workstation-II can be used safely thanks to active cooling.
Additional information
| Chassis | Robust sheet steel chassis for in-vehicle use |
|---|---|
| Dimensions (W x H x D) | 330 x 196 x 410 mm |
| Cooling | Active, 1x 120 mm fan |
| Operating Temperature | 0° ~ 55° C |
| Processor | Intel® Core™ i CPUs 10th Generation (up to max. i9-10900) |
| RAM | max. 128 GB DDR4 |
| Mass Storage | Internal: 2x 2.5" |
| I/O | 2x 1 GBit LAN (RJ45) |
| Expansions (mechanical) | 1x M.2 (M-key, Type: 2280) |
| Power Supply | 10 ~ 48 VDC (In-Vehicle suitable) |
| Chipset | Intel® Q470E |
| Supported Operating Systems | Microsoft® Windows® 10 |
| Weight | 9.5 kg |
Do you need help finding the right system? Our specialists will be happy to support you!
