Additional information
| Mainboard / Backplane | Industrial Mainboard (ATX), 24/7 operation, long-term available |
|---|---|
| Processor | AMD® EPYC™ 7003/7002, Socket SP3 |
| RAM | 8x DDR4 RDIMM/LRDIMM |
| Graphic Card | AST2500, 512 MB DDR4, OnBoard |
| I/O | 2x 10 GBit LAN (RJ45) |
| Mass Storage | Internal: 2x M.2 (one M.2 slot depending on slot configuration) |
| Power Supply | 90 ~ 264 VAC |
| Expansions (mechanical) | 1x PCIe x16 (Gen 4) |
| Chassis | 19" 4 U rackmount chassis |
| Dimensions (W x H x D) | 483 x 177 x 571 mm |
| Cooling | Active, 3x 120 mm fans |
| Operating Temperature | 0° ~ 35° C |
| Storage Temperature | -20° ~ 70° C |
| Relative Humidity (operation) | 10 ~ 90 % (non condensing) |
| IP Protection Class | IP20 |
| Supported Operating Systems | Microsoft® Windows® 11 |
